MIL-H-15362B(Aer)
Characteristics of Racks-
3.5
Function - Racks shall secure and position the equipment which is being tested.
3. 5.1
Position - Racks shall position the equipment or systems under test so as
3. 5.2
to facilitate the adjustment, alignment testing under power, repair and replacement of components.
When necessary, the racks shall allow repositioning Of the equipment either by rotation about one
or more axes or by repositioning within a fixed rack.
Locks - Simple, quick acting locks shall be provided to assure securing the
3. 5.3
racks in any allowable position.
Character istics of Clamps and Brackets.
3.6
Function - Clamps and brackets shall secure the equipment (see 6. 2) in fixed
positions
Position - Clamps and brackets shall position the equipment in such a manner
3. 6.2
.
as to allow normal operation.
Attachment - Clamps and brackets shall provide for simple and quick attach-
3.63
ment of the equipment, to the greatest extent practicable.
Characteristics of Junction Boxes
3.7
Function - Junction boxes shall provide for electrically and mechanically
3. 7.1
joining cable assembles of the test bench harness.
Mounting - Junction boxes shall be designed for installation on work benches
3. 7.2
as required by 3. 1. 3.1.
Quantity and Type - Normally, the test bench harness shall include junction
3. 7.3
boxes of the same type, design and quantity as those used in the installation of the equipment in the
aircraft or guided missile. In particular cases, additional types, designs or quantities of junction
boxes may be included when it can be demonstrated that this will result in economy, reduction in
size or weight. simplificatoin or facilitate installation and use of test bench harness.
Characteristics of Cable Assemblies
3.8
Types - Cable assemblies shall consist of interconnecting cable assembles
3. 8.1
and special test cable assemblies,
Function of Interconnecting Cable Assemblies - The interconnecting cable
3. 8.2
shall provide for electrical connection of units to allow normal operation of the equipment.
Quantity And Types of Interconnect ting Cable Assemblies - Normally the test
3. 8.3
bench h harness shall include interconnecting cable assemblies of the same type, design and quantity
as those used in the installation of the equipment in the aircraft or guided missile. In particular
cases, additional types, designs or quantities of interconnecting cables may be included when it can
be demonstrated that this will result in economy, reduction in size or weight, simplification or
will facilitate Installation and use of the test bench harness.
- -8.4
3. - - -
Function of Special Test Cable Assembles - Special test cable assemblies,
which normally are not required or supplies in the installation of the-equipment, shall be provided
when special electrical connections are required m the testing and maintenance of the equipment.
